Shader Memory Atlas

Introduction

Shader Memory Atlas gives Unreal Engine developers a clear, actionable view of GPU memory consumption during level authoring. When building levels it is difficult to know which assets are consuming the most VRAM, or to find which actors are responsible for memory spikes. This plugin addresses that problem directly.

The plugin scans every loaded texture, material, shader, and static mesh, ranks each asset by memory footprint, and presents the results in a dockable editor panel. A live color-coded heatmap overlays all level actors so expensive objects are visible in the viewport at a glance — no console commands required.

Features

Specifications

Memory Calculation Methods

Pixel format coverage: DXT1 (0.5 bpp), DXT5 (1 bpp), BC7 (1 bpp), RGBA8 (4 bpp), half-float (8 bpp), float (16 bpp). Values are estimates; exact GPU allocation varies by driver, hardware, and streaming state.

Installation

Quick Start

1 — Open the panel

Window  →  Shader Memory Atlas

2 — Scan memory

Click Refresh. The plugin iterates all loaded assets and populates the four lists with per-asset memory estimates. A full scan typically completes in 1–5 seconds depending on level size.

3 — Read the results

The dashboard at the top of the panel displays total GPU memory and current driver-reported usage. The four lists below show the highest-cost assets in each category. Double-click any row to select and focus that asset in the Content Browser.

4 — Enable the heatmap

Click Enable Heatmap. Actors are immediately color-coded:

Drag the Intensity slider if colors are hard to read in bright scenes. Click Disable Heatmap to restore all original materials instantly.

5 — Export a report

Click Export CSV. Open <Project>/Saved/MemoryAtlasReport.csv in a spreadsheet application and sort by size to find the largest optimization targets.

FVRAMTracker API

FVRAMTracker is a stateless static class. No instance is required. All functions are safe to call from any editor context.

Full scene scan

FVRAMTracker::FMemoryStats Stats = FVRAMTracker::ScanMemoryUsage();

// Stats.TotalVRAM     — driver-reported total GPU memory (bytes)
// Stats.UsedVRAM      — driver-reported used GPU memory (bytes)
// Stats.TextureMemory — aggregate of all texture entries
// Stats.TopTextures   — TArray<FMemoryEntry> sorted by SizeBytes desc

Individual asset queries

int64 TexSize  = FVRAMTracker::GetTextureMemorySize(MyTexture);
int64 MatSize  = FVRAMTracker::GetMaterialMemorySize(MyMaterial);
int64 InstSize = FVRAMTracker::GetMaterialInstanceMemorySize(MyInstance);
int64 MshSize  = FVRAMTracker::GetStaticMeshMemorySize(MyMesh);

Per-actor and per-level breakdown

TArray<FVRAMTracker::FMemoryEntry> Entries =
    FVRAMTracker::GetActorMemoryUsage(MyActor);

TArray<FVRAMTracker::FMemoryEntry> LevelEntries =
    FVRAMTracker::GetLevelMemoryUsage(MyLevel);

RHI driver query and formatting

int64 Total, Used;
FVRAMTracker::GetRHIMemoryStats(Total, Used);

FString Human = FVRAMTracker::FormatBytes(Bytes); // e.g. "512.00 MB"

Data structures

struct FMemoryEntry
{
    FString   Name;        // Asset display name
    FString   Type;        // "Texture" | "Material" | "Shader" | "Mesh"
    int64     SizeBytes;   // Estimated memory in bytes
    UObject*  Object;      // Raw pointer to the asset
    FString   AssetPath;   // Content Browser path
};

struct FMemoryStats
{
    int64 TotalVRAM, UsedVRAM;
    int64 TextureMemory, MaterialMemory, ShaderMemory, MeshMemory;

    TArray<FMemoryEntry> TopTextures;
    TArray<FMemoryEntry> TopMaterials;
    TArray<FMemoryEntry> TopShaders;
    TArray<FMemoryEntry> TopMeshes;
};

AMemoryHeatmap API

AMemoryHeatmap is a spawnable actor. All four functions are BlueprintCallable or BlueprintPure and accessible from both C++ and Blueprint graphs.

AMemoryHeatmap* Heatmap = World->SpawnActor<AMemoryHeatmap>();

// Apply the heatmap overlay
Heatmap->SetHeatmapEnabled(true);

// Adjust emissive brightness — range 0.1 to 10.0, default 1.0
Heatmap->SetIntensity(2.0f);

// Re-scan the level and reapply colors
Heatmap->RefreshHeatmap();

// Restore all original materials
Heatmap->SetHeatmapEnabled(false);

// Static pure helper — compute the heatmap color for any cost / max pair
FLinearColor Color = AMemoryHeatmap::GetHeatmapColor(ActorCost, MaxCost);

Blueprint function reference

Color encoding algorithm

ratio = ActorCost / MaxCost

ratio 0.00 – 0.50  →  lerp  Green  (0, 1, 0)  →  Yellow  (1, 1, 0)
ratio 0.50 – 1.00  →  lerp  Yellow (1, 1, 0)  →  Red     (1, 0, 0)

final_emissive = color * IntensityMultiplier

Editor Panel

SShaderMemoryAtlasWidget is a Slate SCompoundWidget rendered inside a registered dockable tab. Open it from Window → Shader Memory Atlas.

┌─ Toolbar ────────────────────────────────────────────┐
│  [ Refresh ]   [ Export CSV ]                            │
├─ Memory Overview ────────────────────────────────────────┬
│  Total VRAM: 8.00 GB          Used: 3.21 GB              │
├─ Textures ───────────────┼─ Materials ───────────────┘
│  T_Rock_Diffuse   128.00 MB  │  M_Rock          45.00 KB  │
│  T_Sky_HDRI        64.00 MB  │  M_Foliage_Base  38.00 KB  │
├─ Shaders ───────────────┼─ Meshes ───────────────────┘
│  SH_Foliage        22.00 KB  │  SM_Building     3.20 MB   │
│  SH_Water          18.00 KB  │  SM_Tree_Hero    1.80 MB   │
├─ Heatmap Controls ──────────────────────────────────┘
│  [ Enable Heatmap ]    Intensity: ──────⬤──────  2.0    │
└───────────────────────────────────────────────────────────└

Control reference

System Design

Build Configuration

The module type is Editor with loading phase Default. The PlatformAllowList restricts compilation to Win64, Mac, and Linux — the module never compiles against game targets or any mobile platform.

PublicDependencyModuleNames.AddRange(new string[]
{
    "Core", "CoreUObject", "Engine",
    "RenderCore", "RHI", "Renderer", "ShaderCore"
});

PrivateDependencyModuleNames.AddRange(new string[]
{
    "UnrealEd", "Slate", "SlateCore",
    "MaterialEditor", "AssetRegistry",
    "LevelEditor", "PropertyEditor",
    "Json", "JsonUtilities"
});

Performance Characteristics

All heavy work runs on the game thread during the explicit scan phase triggered by clicking Refresh. No background threads or per-frame queries are active when the heatmap is disabled.

Optimization Guide

Recommended workflow

Texture guidelines

• Prefer DXT1 for opaque surfaces and DXT5 / BC7 for surfaces with alpha
• Enable mip maps on all textures — the engine streams lower mips for distant geometry
• Reducing resolution from 4K to 2K is often unnoticeable and halves texture memory
• Enable texture streaming for large open-world levels
• Avoid uncompressed RGBA8 except for render targets that require full precision

Material guidelines

• Share a single base UMaterial; use UMaterialInstance for per-object parameter variation
• Fewer shader nodes means a smaller compiled permutation cache
• Use static switches to compile out unused feature branches
• Avoid creating a unique base material for every prop in the level

Mesh guidelines

• Add LOD levels — background geometry at 100 m rarely needs more than 500 triangles
• Remove unused UV channels; each adds per-vertex data across all LODs
• Use Hierarchical Instanced Static Meshes (HISMs) for foliage and repeated props
• Decimate high-polygon background objects using the built-in mesh reduction tool

VRAM Budgets

Reference budgets for common target platforms. Values are recommendations, not hard limits.

Troubleshooting

Diagnostic commands

Check Window → Developer Tools → Output Log and filter by Shader Memory Atlas for detailed per-operation logging.

stat memory          — system and GPU memory overview
stat rhi             — RHI-level GPU statistics
stat gpu             — per-pass GPU timing
stat scenerendering  — scene rendering statistics
